Features:

  • AC and DC designs
  • Flange or base mounting
  • Alnico permanent magnet rotors (AC)/(DC) fields
  • Compact design
  • Operational in either rotation or reversing device
  • No vent openings (non airtight) to prevent free exchange of air
  • eXcellon product built based on GE originally created drawings and specifications
  • Medium accuracy used with regulated drive or speed indicated
  • eXcellon nameplate will reflect General Electric model number!

Applications:

  • Speed control on a variety of mill drives
  • Machine tools
  • Paper machines
  • Speed-regulated drive scheme

Available models (but not limited to):

AC Tachometer Generators

RPM Volts/ 1000 rpm GE frame NEMA Frame Base Former GE Catalog No. Model No. List Price (USD)* Wgt. C’ Dim.
400-5000 20 18 GE59 WB D246 5PY59EY4 $1,977.58 5 6.4
400-5000 28 18 GE59 WB D121 5PY59EY3 $1,269.39 4 6
400-5000 28 18 GE59 FLG D120 5PY59EY2 $1,207.92 5 6

*Please contact us at +1-855-503-9159 or contact@excellonmotors.com for price and availability

FLG =Flange mounted      WB =Welded base

DC Tachometer Generators

RPM Volts/ 1000 rpm GE frame NEMA Frame Base Former GE Catalog No. Model No. List Price (USD)* Wgt. C’ Dim.
100-2500 100 18 GE59 FLG D122 5PY59JY1 $2,645.68 8 7.5
100-2500 100 18 GE59 FLG D250 5PY59JY85 $2,875.50 8 7.5 (2 slots per coil)
100-2500 100 18 GE59 WB D124 5PY59JY23 $2,699.12 7 7.5
100-5000 50 18 GE59 FLG D123 5PY59JY2 $2,645.68 7 7.5
100-5000 50 18 GE59 FLG D252 5PY59JY3 $2,792.66 7 7.5
100-5000 50 18 GE59 FLG D251 5PY59JY84 $2,899.55 7 7.5
100-5000 50 18 GE59 WB D125 5PY59JY24 $2,699.12 7 7.5

*Please contact us at +1-855-503-9159 or contact@excellonmotors.com for price and availability

FLG = Flange mounted      WB = Welded base     NB = No base

Other examples (but not limited to):

  • ​5PY59JY27 originally for Reliance
  • 5PY59JY28 originally for Reliance
  • 5PY59JY29 originally for Reliance
  • 5PY59JY30 originally for Reliance
  • 5PY59JY31 originally for Reliance
  • 5PY59JY34 originally for Reliance
  • 5PY59JY35 originally for Reliance
  • 5PY59JY37 originally for Reliance
  • 5PY59JY38 originally for Reliance
  • 5PY59JY39 originally for Reliance
  • 5PY59JY44 originally for Reliance
  • 5PY59JY46
  • 5PY59JY49 originally for Reliance
  • 5PY59JY51 originally for Reliance
  • 5PY59JY54 originally for Reliance
  • 5PY59JY55
  • 5PY59JY60
  • 5PY69JY61 originally for Reliance
  • 5PY59JY62 originally for Reliance
  • 5PY59JY70 originally for Reliance
  • 5PY59JY73 originally for Reliance
  • 5PY59JY74 originally for Reliance
  • 5PY59JY75 originally for Reliance
  • 5PY59JY78 originally for Reliance
  • 5PY59JY79 originally for Reliance
  • 5PY59JY80 originally for Reliance
  • 5PY59JY87 originally for Reliance
  • 5PY59JY87 originally for Reliance
  • 5PY59JY88 originally for Reliance
  • 5PY59JY109 originally for Reliance
  • 5PY59JY110 originally for Reliance
  • 5PY59JY111 originally for Reliance
  • 5PY59JY112 originally for Reliance
  • 5PY59JY115

FLG = Flange mounted      WB = Welded base     NB = No base
